E-Mobility and Battery Testing

Improving Battery Pack Structural Performance

Optimizing the mechanical and structural design of battery packs is essential to the development and manufacturing of lightweight and durable packs. Dielectric and small fiber optic sensors provide new measurement capabilities essential to design and process optimization.

A Better Alternative to Strain Gauges

Luna’s high-definition fiber optic sensing (HD-FOS) provides a revolutionary measurement tool for battery system testing Battery pack testingand analysis. HD-FOS strain sensors can be embedded in or mounted on battery cells, battery pouches and packs to provide distributed strain measurements for model verification, durability testing and damage detection. HD-FOS sensors can deliver thousands of precision strain measurements distributed throughout a battery system with a single optical fiber compared to only a few strain gage measurement locations.

Immune to electromagnetic interference (EMI) and high voltages, inherently dielectric and corrosion-resistant, fiber optic sensors avoid the problems and risks of using metallic foil gages and copper wiring to instrument a battery.

Additionally, the very small diameter and flexibility of HD-FOS sensors make them an ideal match for strain measurements on composite materials and components, which are prevalent in battery pack systems.



Featured Products

ODiSI 7100 System

High-Definition Distributed Fiber Optic Sensing

HD Sensors

High-Definition Sensors

HYPERION si255 interrogator

High-Speed Multipoint Fiber Optic Sensing

os3200 strain sensor

FBG and FP Sensors

ODiSI 7100 System

High-Definition Distributed Fiber Optic Sensing

Unlike conventional strain gauges that only measure strain at a discrete point, Luna's high definition fiber optic strain gauges provide continuous, high-resolution (less than 1 mm) measurements of strain along the entire length of the sensor (up to 50m).
HD Sensors

High-Definition Sensors

Unlike conventional strain gauges that only measure strain at a discrete point, Luna's high definition fiber optic strain gauges provide continuous, high-resolution (less than 1 mm) measurements of strain along the entire length of the sensor (up to 100 m).
